Hitting Granulating Machine

1,Overview

    Hitting granulating machine is lately developmental new kind of crusher equipment. This kind of machine is designed for small-scale gold processing plant, especially adapt to free gold recovery. Assembled with Centrifugal Concentrator or jig can establish a processing plant, and it is very effective to recovery free gold. Since the technologic process doesn’t need add any chemicals, it is environment friendly. Using the advanced crushing structure, the crusher can achieve crush and grinding at one time. Choosing Mn13 (High Manganese Material) the hammer head is longer life. It is especially suitable for the remote region, because of the simple structure, easy operation，maintenance and convenient for moving. You can operate it without receiving any special training.

2,Structure

    The motor drives the rotor rotates of the Hitting granulating machine at a high speed through the belt, and on the rotor there are series hammers. When the materials get into the working area of hammers, they are crushed by the rotating hammers of the hammer crusher with high rotation speed, the materials which are crushed to meet the required size can be discharged by the outlet and become the final products, the large size products are brought back to the crushed area by the hammers of the hammer crusher for being refreshed Until they reached the required size.

3,Technical Specifications
